Docker部署环境

柳意梧情
2022-05-29 / 1 评论 / 10 点赞 / 686 阅读 / 0 字 / 正在检测是否收录...

一、docker安装mysql

1、拉取mysql镜像

docker pull mysql

2、创建 mysql文件夹

mkdir -p /data/mysql/conf

3、创建mysql配置文件

touch /data/mysql/conf/my.cnf

4、编辑my.cnf文件

vi /data/mysql/conf/my.cnf

5、输入如下内容:

# Copyright (c) 2017, Oracle and/or its affiliates. All rights reserved.
#
# This program is free software; you can redistribute it and/or modify
# it under the terms of the GNU General Public License as published by
# the Free Software Foundation; version 2 of the License.
#
# This program is distributed in the hope that it will be useful,
# but WITHOUT ANY WARRANTY; without even the implied warranty of
# MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
# GNU General Public License for more details.
#
# You should have received a copy of the GNU General Public License
# along with this program; if not, write to the Free Software
# Foundation, Inc., 51 Franklin St, Fifth Floor, Boston, MA  02110-1301 USA

#
# The MySQL  Server configuration file.
#
# For explanations see
# http://dev.mysql.com/doc/mysql/en/server-system-variables.html

[mysqld]
pid-file        = /var/run/mysqld/mysqld.pid
socket          = /var/run/mysqld/mysqld.sock
datadir         = /var/lib/mysql
secure-file-priv= NULL
# Disabling symbolic-links is recommended to prevent assorted security risks
symbolic-links=0

# Custom config should go here
!includedir /etc/mysql/conf.d/

default_authentication_plugin= mysql_native_password

6、运行mysql容器

docker run \
       -p 3306:3306 \
       -e MYSQL_ROOT_PASSWORD=pass \
       -v /data/mysql/data:/var/lib/mysql:rw \
       -v /data/mysql/log:/var/log/mysql:rw \
       -v /data/mysql/conf/my.cnf:/etc/mysql/my.cnf:rw \
       -v /etc/localtime:/etc/localtime:ro \
       --name mysql \
       --restart=always \
       -d mysql

二、docker安装redis

1、拉取redis镜像

docker pull redis

2、创建redis文件夹

mkdir -p /data/redis/conf

3、创建redis配置文件

touch /data/redis/conf/redis.conf

4、编辑redis.conf文件

vi /data/redis/conf/redis.conf

5、输入如下内容:

开启redis 持久化

appendonly yes

6、运行redis容器

docker run \
    -p 6379:6379 \
    -v /data/redis/data:/data:rw \
    -v /data/redis/conf/redis.conf:/etc/redis/redis.conf:rw \
    --name redis \
    --restart=always \
    -d redis redis-server /etc/redis/redis.conf

三、docker安装nacos

1、拉取nacos镜像

docker pull nacos/nacos-server

2、创建nacos文件夹

mkdir -p /data/nacos/logs
mkdir -p /data/nacos/conf

3、创建nacos配置文件

touch /data/nacos/conf/application.properties

4、编辑application.properties文件

vi /data/nacos/conf/application.properties

5、输入如下内容:

注意修改为自己的数据库信息

server.contextPath=/nacos
server.servlet.contextPath=/nacos
server.port=8848

spring.datasource.platform=mysql

db.num=1
db.url.0=jdbc:mysql://192.168.56.10:3306/nacos_config?characterEncoding=utf8&connectTimeout=1000&socketTimeout=3000&autoReconnect=true
db.user=root
db.password=pass

nacos.cmdb.dumpTaskInterval=3600
nacos.cmdb.eventTaskInterval=10
nacos.cmdb.labelTaskInterval=300
nacos.cmdb.loadDataAtStart=false

management.metrics.export.elastic.enabled=false

management.metrics.export.influx.enabled=false

server.tomcat.accesslog.enabled=true
server.tomcat.accesslog.pattern=%h %l %u %t "%r" %s %b %D %{User-Agent}i

nacos.security.ignore.urls=/,/**/*.css,/**/*.js,/**/*.html,/**/*.map,/**/*.svg,/**/*.png,/**/*.ico,/console-fe/public/**,/v1/auth/login,/v1/console/health/**,/v1/cs/**,/v1/ns/**,/v1/cmdb/**,/actuator/**,/v1/console/server/**
nacos.naming.distro.taskDispatchThreadCount=1
nacos.naming.distro.taskDispatchPeriod=200
nacos.naming.distro.batchSyncKeyCount=1000
nacos.naming.distro.initDataRatio=0.9
nacos.naming.distro.syncRetryDelay=5000
nacos.naming.data.warmup=true
nacos.naming.expireInstance=true

6、运行nacos容器

docker run \
       -p 8848:8848 --name nacos \
       -e PREFER_HOST_MODE=192.168.56.10 \
       -e MODE=standalone \
       -e SPRING_DATASOURCE_PLATFORM=mysql \
       -e MYSQL_MASTER_SERVICE_HOST=192.168.56.10 \
       -e MYSQL_MASTER_SERVICE_PORT=3306 \
       -e MYSQL_MASTER_SERVICE_USER=root \
       -e MYSQL_MASTER_SERVICE_PASSWORD=pass \
       -e MYSQL_MASTER_SERVICE_DB_NAME=nacos_config \
       -v  /data/nacos/logs:/home/nacos/logs \
       -v /data/nacos/conf/custom.properties:/home/nacos/conf/application.properties \
       --restart=always \
       -d nacos/nacos-server

四、docker安装seata

1、拉取seata镜像

docker pull seataio/seata-server

2、创建seata文件夹

mkdir -p /data/seata/conf

3、创建配置文件file.conf和registry.conf

touch /data/seata/conf/file.conf
touch /data/seata/conf/registry.conf

4、编辑file.conf和registry.conf文件

{tabs-pane 编辑file.conf文件}
vi file.conf
## transaction log store, only used in seata-server
store {
  ## store mode: file、db、redis
  mode = "db"
  ## database store property
  db {
    ## the implement of javax.sql.DataSource, such as DruidDataSource(druid)/BasicDataSource(dbcp)/HikariDataSource(hikari) etc.
    datasource = "druid"
    dbType = "mysql"
    driverClassName = "com.mysql.cj.jdbc.Driver"
    url = "jdbc:mysql://192.168.56.10:3306/seata?useUnicode=true&characterEncoding=UTF-8&serverTimezone=Asia/Shanghai"
    user = "root"
    password = "pass"
    minConn = 5
    maxConn = 100
    globalTable = "global_table"
    branchTable = "branch_table"
    lockTable = "lock_table"
    queryLimit = 100
    maxWait = 5000
  }
}
{/tabs-pane} {tabs-pane 编辑registry.conf文件}
vi registry.conf
registry {
  # file 、nacos 、eureka、redis、zk、consul、etcd3、sofa
  type = "nacos"
  nacos {
    application = "seata-server"
    serverAddr = "192.168.56.10:8848"
    namespace = "seata"
    group = "SEATA_GROUP"
    cluster = "default"
    username = "nacos"
    password = "nacos"
  }
  file {
    name = "file.conf"
  }
}
config {
  # file、nacos 、apollo、zk、consul、etcd3
  type = "nacos"
  nacos {
    serverAddr = "192.168.56.10:8848"
    namespace = "seata"
    group = "SEATA_GROUP"
    username = "nacos"
    password = "nacos"
  }
  file {
    name = "file.conf"
  }
}
{/tabs-pane}

6、推送seata配置到nacos

sh ${SEATAPATH}/script/config-center/nacos/nacos-config.sh -h localhost -p 8848 -g SEATA_GROUP -t 5a3c7d6c-f497-4d68-a71a-2e5e3340b3ca -u username -w password

参数说明:

-h:主机,默认值为localhost。

-p:端口,默认值为8848。

-g:配置分组,默认值为’SEATA_GROUP’。

-t:命名空间,对应Nacos的namespace ID字段,默认值为’'。

-u:用户名,nacos 1.2.0+ 权限控制,默认为’'。

-w:密码,nacos 1.2.0+ 关于权限控制,默认值为’'。

官方说明

推送脚本可前往官方地址下载:链接

下面贴出我的,在目录 /data/seata下创建下面两个文件,之后直接执行下面的推送命令即可,注意路径一致

{tabs-pane config.txt文件}
vi config.txt
store.db.datasource=druid
store.db.dbType=mysql
store.db.driverClassName=com.mysql.jdbc.Driver
store.db.url=jdbc:mysql://192.168.56.10:3306/seata?useUnicode=true
store.db.user=root
store.db.password=pass
store.db.minConn=5
store.db.maxConn=30
store.db.globalTable=global_table
store.db.branchTable=branch_table
store.db.queryLimit=100
store.db.lockTable=lock_table
store.db.maxWait=5000
{/tabs-pane} {tabs-pane nacos-config.sh文件}
vi nacos-config.sh
#!/usr/bin/env bash
# Copyright 1999-2019 Seata.io Group.
#
# Licensed under the Apache License, Version 2.0 (the "License");
# you may not use this file except in compliance with the License.
# You may obtain a copy of the License at、
#
#      http://www.apache.org/licenses/LICENSE-2.0
#
# Unless required by applicable law or agreed to in writing, software
# distributed under the License is distributed on an "AS IS" BASIS,
# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
# See the License for the specific language governing permissions and
# limitations under the License.
while getopts ":h:p:g:t:u:w:" opt
do
  case $opt in
  h)
    host=$OPTARG
    ;;
  p)
    port=$OPTARG
    ;;
  g)
    group=$OPTARG
    ;;
  t)
    tenant=$OPTARG
    ;;
  u)
    username=$OPTARG
    ;;
  w)
    password=$OPTARG
    ;;
  ?)
    echo " USAGE OPTION: $0 [-h host] [-p port] [-g group] [-t tenant] [-u username] [-w password] "
    exit 1
    ;;
  esac
done
urlencode() {
  for ((i=0; i < ${#1}; i++))
  do
    char="${1:$i:1}"
    case $char in
    [a-zA-Z0-9.~_-]) printf $char ;;
    *) printf '%%%02X' "'$char" ;;
    esac
  done
}
if [[ -z ${host} ]]; then
    host=localhost
fi
if [[ -z ${port} ]]; then
    port=8848
fi
if [[ -z ${group} ]]; then
    group="SEATA_GROUP"
fi
if [[ -z ${tenant} ]]; then
    tenant=""
fi
if [[ -z ${username} ]]; then
    username=""
fi
if [[ -z ${password} ]]; then
    password=""
fi
nacosAddr=$host:$port
contentType="content-type:application/json;charset=UTF-8"
echo "set nacosAddr=$nacosAddr"
echo "set group=$group"
failCount=0
tempLog=$(mktemp -u)
function addConfig() {
  curl -X POST -H "${contentType}" "http://$nacosAddr/nacos/v1/cs/configs?dataId=$(urlencode $1)&group=$group&content=$(urlencode $2)&tenant=$tenant&username=$username&password=$password" >"${tempLog}" 2>/dev/null
  if [[ -z $(cat "${tempLog}") ]]; then
    echo " Please check the cluster status. "
    exit 1
  fi
  if [[ $(cat "${tempLog}") =~ "true" ]]; then
    echo "Set $1=$2 successfully "
  else
    echo "Set $1=$2 failure "
    (( failCount++ ))
  fi
}
count=0
for line in $(cat /data/seata/config.txt | sed s/[[:space:]]//g); do
  (( count++ ))
    key=${line%%=*}
    value=${line#*=}
    addConfig "${key}" "${value}"
done
echo "========================================================================="
echo " Complete initialization parameters,  total-count:$count ,  failure-count:$failCount "
echo "========================================================================="
if [[ ${failCount} -eq 0 ]]; then
    echo " Init nacos config finished, please start seata-server. "
else
    echo " init nacos config fail. "
fi
{/tabs-pane}

推送命令

sh nacos-config.sh -h 192.168.56.10 -p 8848 -g SEATA_GROUP -t seata -u nacos -w nacos

7、运行seata容器

docker run \
       -p 8091:8091 --name seata \
       -e SEATA_IP=192.168.56.10 \
       -e SEATA_PORT=8091 \
       -v /data/seata/conf/registry.conf:/seata-server/resources/registry.conf \
       -v /data/seata/logs:/root/logs \
       --privileged=true \
       --restart always \
       -d seataio/seata-server

五、docker安装sentinel

1、拉取sentinel镜像

docker pull bladex/sentinel-dashboard

2、运行sentinel容器

docker run \
       -p 8858:8858 --name sentinel \
       --restart always \
       -d  bladex/sentinel-dashboard

六、docker安装rabbitMq

1、拉取rabbitMq镜像

docker pull rabbitmq

2、创建rabbitMq文件夹

mkdir -p /data/rabbitmq

3、运行rabbitMq容器

docker run \
       -p 5672:5672 -p 15672:15672 --name rabbitmq \
       -v /data/rabbitmq:/var/lib/rabbitmq \
       -e RABBITMQ_DEFAULT_USER=admin \
       -e RABBITMQ_DEFAULT_PASS=admin \
       --restart always \
       -d rabbitmq

4、安装插件

docker exec -t rabbitmq rabbitmq-plugins enable rabbitmq_management

5、重启rabbitMq容器

七、docker安装fastDFS

1、拉取fastDFS镜像

docker pull season/fastdfs:1.2

2、创建fastDFS文件夹

mkdir -p /data/fastdfs/tracker/data
mkdir -p /data/fastdfs/storage/data
mkdir -p /data/fastdfs/storage/path

3、创建tracker容器

docker run \
       -id --name tracker \
       -p 22122:22122 \
       -v /data/fastdfs/tracker/data:/fastdfs/tracker/data \
       --restart=always --net host \
       season/fastdfs:1.2 tracker

4、创建storage容器

docker run \
       -id --name storage \
       -v /data/fastdfs/storage/data:/fastdfs/store_path \
       -e TRACKER_SERVER=192.168.56.30:22122 \
       --restart=always --net host \
       season/fastdfs:1.2 storage

5、复制tracker配置文件

docker cp tracker:/etc/fdfs/client.conf /data/fastdfs/tracker/
docker cp /data/fastdfs/tracker/client.conf tracker:/etc/fdfs

6、复制storage配置文件

docker cp storage:/etc/fdfs/client.conf /data/fastdfs/storage/
docker cp /data/fastdfs/storage/client.conf storage:/etc/fdfs

7、测试连接

fdfs_monitor client.conf

8、测试上传

echo "hello lywq" > hello.txt
fdfs_upload_file /etc/fdfs/client.conf hello.txt

9、创建fastdfs使用的nginx文件夹

mkdir -p /data/fastdfs/nginx

10、创建文件

docker cp storage:/etc/nginx/conf/nginx.conf /data/fastdfs/nginx/

11、配置nginx路由

location / {
  root /fastdfs/store_path/data;
  ngx_fastdfs_module;
}

12、运行fastdfs_nginx容器

docker run  \
       -id --name fastdfs_nginx \
       -p 8866:80 \
       -e TRACKER_SERVER=192.168.56.30:22122 \
       -v /data/fastdfs/storage/data:/fastdfs/store_path \
       -v /data/fastdfs/nginx/nginx.conf:/etc/nginx/conf/nginx.conf \
       --restart=always \
       season/fastdfs:1.2 nginx

八、docker安装Elastic search

1、拉取elasticsearch镜像

docker pull elasticsearch:7.3.0

2、创建elasticsearch文件夹

mkdir -p /data/elasticsearch/config
mkdir -p /data/elasticsearch/data
mkdir -p /data/elasticsearch/logs
mkdir -p /data/elasticsearch/plugins

chmod -R 777 /data/elasticsearch/

3、创建配置文件

简单启动一下 ,把镜像里面的elasticsearch.yml给cp出来,方便做映射
docker run -d --name elasticsearch elasticsearch:7.3.0
docker cp elasticsearch:/usr/share/elasticsearch/config/elasticsearch.yml /data/elasticsearch/config/

4、修改elasticsearch存储目录

不建议使用,设置了新的存储目录需要赋予权限

# 存储目录
path.data: /data/elasticsearch/data
path.logs: /data/elasticsearch/logs

5、运行elasticsearch容器

docker run \
       -p 9200:9200 -p 9300:9300 --name elasticsearch \
       -e "cluster.name=elasticsearch" \
       -e "discovery.type=single-node" \
       -e ES_JAVA_OPTS="-Xms64m -Xmx512m" \
       -v /data/elasticsearch/config/elasticsearch.yml:/usr/share/elasticsearch/config/elasticsearch.yml \
       -v /data/elasticsearch/data:/usr/share/elasticsearch/data \
       -v /data/elasticsearch/logs:/usr/share/elasticsearch/logs \
       -v /data/elasticsearch/plugins:/usr/share/elasticsearch/plugins \
       --restart always \
       -d elasticsearch:7.3.0

6、查看日志验证是否启动成功

docker logs -f elasticsearch

7、设置密码

修改配置文件

#安全配置
xpack.security.enabled: true
xpack.security.transport.ssl.enabled: true

重启elasticsearch

docker restart elasticsearch

进入容器

docker exec -it elasticsearch bash

设置密码

./bin/elasticsearch-setup-passwords interactive

8、日志报错解决

sqoop报错:
ERROR Could not register mbeans java.security.AccessControlException: access denied ("javax.management.MBeanTrustPermission" "register")

解决方法:
修改jdk的文件jdk1.8.0_11/jre/lib/security/java.policy

具体配置如下:在文件中添加如下内容

grant {
        permission javax.management.MBeanTrustPermission "register";
};

10、安装ik中文分词插件

ik中文分词插件

九、docker安装kibana

1、拉取kibana镜像

docker pull kibana:7.3.0

2、创建kibana文件夹

mkdir -p /data/kibana/config

3、创建配置文件

docker inspect elasticsearch IPAddress
vi /data/kibana/config/kibana.yml
#
# ** THIS IS AN AUTO-GENERATED FILE **
#

# Default Kibana configuration for docker target
server.name: kibana
server.port: 5601
server.host: "0.0.0.0"
elasticsearch.hosts: ["http://192.168.56.30:9200"]
xpack.monitoring.ui.container.elasticsearch.enabled: true
kibana.index: ".kibana"
i18n.locale: "zh-CN"
elasticsearch.username: "elastic"
elasticsearch.password: "elastic"

4、运行kibana容器

docker run \
       -p 5601:5601 --name kibana \
       -v /data/kibana/config/kibana.yml:/usr/share/kibana/config/kibana.yml \
       --restart always \
       -d kibana:7.3.0

5、查看日志验证是否启动成功

docker logs -f kibana

十、docker安装canal-server

1、拉取canal-server镜像

docker pull canal/canal-server:v1.1.6
10

评论区
